ER100S-1 High Strength and High Impact TIG Welding Rods

ER100S-1 High Strength and High Impact TIG Welding Rods

$24.14Price

Alloy ER1100 is highly resistant to chemical
attack and weathering. It is a relatively soft
alloy that is very formable and is used
extensively in thin gauge and foil products.
It has good welding characteristics and it
is also used as a filler alloy for welding
purposes. A desirable characteristic of the
alloy is the bright finishes obtained by
anodizing. Base metals that can be welded
are 1060, 1070, 1080, and 3003.


Applications
• Heat Exchangers
• Food Handling Equipment
• Rivets
• Tie Wire
• Metallizing


AWS Specification
AWS A5.10/A5.10M:1999(R2007)
AWS Classification ER1100


Welding Current

DCEP


Typical Wire Chemistry
Si a
Fe a
Cu 0.05 - 0.20
Mn 0.05
Zn 0.10
OTHER .15
AI 99.00 min


Typical Properties
Melting range 1190 - 1215ºF
Conductivity 59% IACS ( - H12)
Density 0.98 lbs/cu in
Anodized color Gray
Tensile Strength, ksi 13


Welding Positions
All positions


Available Diameters GMAW and
suggested Operating Range in Amps

.030" 100 - 120
.035" 110 - 170
3/64" 150 - 190
1/16" 200 - 300
3/32" 320 - 330


Available Diameters GTAW
1/16", 3/32" & 1/8''


a – Silicon plus iron shall
not exceed 0.95%

Size
Diameter
